6.00mm Galvanized Steel Coils Hot Rolled Metal 30 - 275g / M2 Dx51d

Product Categories
Jiangsu Lianzhong Metal Products (Group) Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

6.00mm Galvanized Steel Coils Hot Rolled Metal 30 - 275g / M2 Dx51d

  • 1
  • 2
  • 3

Brand Name : TISCO

Model Number : SGCC SECC SGCD PPGI DX51D DX54D S250GD S550GD

Certification : ce, ISO9001,RoHS, IBR

Place of Origin : Jiangsu，China

MOQ : 1ton

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20000 Ton/Tons per Month

Delivery Time : 3-15 days

Packaging Details : Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers

Standard : AiSi, ASTM, bs, DIN, GB, JIS

Processing Service : Cutting

Application : ROOF

Technique : Cold Rolled

Surface Treatment : galvanized

Width : 762MM/914MM/1000MM

Type : Galvanized Steel coil

Contact Now

— Galvanized Steel Coil —

Description
Hot-dip galvanizing is the reaction of molten metal with an iron substrate to produce an alloy layer, thereby combining the
substrate and the plating layer. Hot-dip galvanizing is to pickle iron and steel parts first. In order to remove iron oxide on the surface of iron and steel parts, after pickling, it is cleaned in an ammonium chloride or zinc chloride aqueous solution or a mixed solution of ammonium chloride and zinc chloride.And then sent to the hot-dip plating bath. Hot-dip galvanizing has the advantages of uniform coating, strong adhesion and long service life.

Technical Standard
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440,
SGH490,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340),
SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s
Requirement
Type
Coil/Sheet/Plate/Strip
Thickness
0.12-6.00mm,or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm
Coil Weight
3-20 metric ton per coil
Package
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement
Export market
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc

STEEL GRADE CHEMICAL COMPOSITION % MECHANIC PROPERTY C.B OF COATING
C Si Mn S P T.S Y.S E.L COATING
x103 x103 x102 x103 x103 Mpa Mpa % d=0 180° G/M²
JIS G3302 SGCC 12 30 41 31 21 480 300 13 OK Z60-150
JIS G3302 SGCH 12 10 21 18 8 680 650 20 OK Z60-150
ASTM A653 CS.B 29 30 60 35 30 386 250-380 20 OK Z60-275
DX51D+Z 20 21 18 1.8 11 355 245 38 OK Z60-275
G550 12 6 73 5 17 715 654 8 OK Z60-275
